ET15 | Eurotech
ET15 Dual Wall Heat Shrink Tube by Eurotech
Adhesive lined semi-flexible heat shrink tubing ideal for applications ranging from general purpose automotive, commercial and marine wire harness bundles, industrial splices, breakouts and back of connector environmental protection.
Description
ET15 Dual Wall Heat Shrink Tube by Eurotech
OEM Cab Splice Sealing | -40 to 110C | EVA Adhesive | Low Viscosity | Flexible, Flame Retardant, Low Shrink Temp Jacket
Applications
- Sealing and strain relief of multi wire splices, terminals and connectors
- Abrasion protection of hose and pipes
- Passenger, commercial vehicles, heavy equipment Fleet and recreational vehicles
- Consumer electronics and white goods
- Meets Ford, GM, Daimler, International, Caterpillar and others, end splice protection requirements
- Technical crossover for Tyco QS1500, DSG IPMK and more
Features
| Features | Benefits |
|---|---|
| 4:1 Shrink Ratio | Use less sizes to fit varying / multiple splice configurations & profiles |
| Semi-Rigid | Excellent protection against corrosive fluids and oils at elevated temperature |
| Stiff, Rugged Outer Jacket | Excellent strain relief, with high impact and abrasion resistance. BK and CR colors available |
| Thick Adhesive Layer | Environmental protection against moisture and contaminants. Bonds readily to PVC, XLPE and PP-EPDM cable jacket |
| Continuous Operating Temperature |
-40°C-110°C |
Additional information
| Model | ET15 |
|---|---|
| Wall Type | Dual Wall |
| Splice Sealing | Yes |
| OEM Approvals (Partial Snapshot) | Ford, GM, John Deere, Stellantis, Volvo Penta, Volvo Truck |
| Crossover Product (Technical) Partial Snapshot | DSG IPMK, TE QS1500 |
| Crossover Product (Application) Partial Snapshot | *One or more attributes may not directly match the referenced product(s), but this Eurotech model is suitable as a replacement for most applications. | TE RPPM (clear) |
| Mode | Shrinkable |
| Shrink Ratio | 4:1, 6:1 |
| ID Supplied / ID Recovered (mm) | 12.0 / 3.0, 16.0 / 4.0, 18.3 / 4.4, 4.0 / 1.0, 6.0 / 1.3, 8.0 / 1.7, 9.0 / 2.3, 9.5 / 1.5 |
| Adhesive Feature | Low Viscosity |
| Material Type | Polyolefin, crosslinked |
| Adhesive Type | EVA |
| Color | Black, Clear |
| Tubing Code | DWS110-40PXOEVL |
| Min Shrink Temp | 80 |
| Min Full Recovery Temp | 110 |
| Length Change | -7+3% |
| Halogen Free | No |
| RoHS | Yes |
| REACH | Yes |
| ELV | Yes |
| MIL | No |
| Low Op Temp | -40 |
| High Op Temp | 110 |
