ET11 | Eurotech
ET11 Dual Wall Heat Shrink Tube by Eurotech
Adhesive lined semi-flexible heat shrink tubing ideal for applications ranging from general purpose automotive, commercial and marine wire harness bundles, industrial splices, breakouts and back of connector environmental protection.
Description
ET11 Dual Wall Heat Shrink Tube by Eurotech
Semi-Flexible, Flame Retardant | -55 to 125C | EVA Adhesive | High Viscosity, Thin
Applications
- Sealing and strain relief of multi wire splices, terminals and connectors
- Abrasion protection of hose and pipes
- Passenger, commercial vehicles, heavy equipment Fleet and recreational vehicles
- Consumer electronics and white goods
- Meets Ford, GM, Daimler, International, Caterpillar and others, end splice protection requirements
- Technical crossover for Tyco TE HTAT, DSG CPA300/IHKT, Sumitube W3B2
Features
| Features | Benefits |
|---|---|
| 4:1 Shrink Ratio | Use less sizes to fit varying / multiple splice configurations & profiles |
| Semi-Rigid | Excellent protection against corrosive fluids and oils at elevated temperature |
| Stiff, Rugged Outer Jacket | Excellent strain relief, with high impact and abrasion resistance. BK, CR, WH, YL, OR and RD colors available |
| Thick Adhesive Layer | Environmental protection against moisture and contaminants. Bonds readily to Plastics, rubber, steel and XLPO able jacket |
| Continuous Operating Temperature |
-55°C-125°C Min full recovery temperature of 110°C |
Additional information
| Model | ET11 |
|---|---|
| Mode | Shrinkable |
| Wall Type | Dual Wall |
| OEM Approvals (Partial Snapshot) | John Deere, MAN Truck & BUS AG, Paccar, Scania, Volvo Construction Equipment, Volvo Penta, Volvo Truck |
| Crossover Product (Technical) Partial Snapshot | |
| Crossover Product (Application) Partial Snapshot | *One or more attributes may not directly match the referenced product(s), but this Eurotech model is suitable as a replacement for most applications. | DSG CPA300, TE BATTU |
| Shrink Ratio | 3:1, 4:1, 5:1 |
| Adhesive Feature | High Viscosity,Thin |
| ID Supplied / ID Recovered (mm) | 12.0 / 3.0, 14.5 / 3.0, 16.0 / 4.0, 20.0 / 4.0, 24.0 / 6.0, 24.2 / 5.0, 32.0 / 8.0, 4.0 / 1.0, 4.8 / 1.6, 48.0 / 13.0, 52.0 / 13.0, 8.0 / 2.0 |
| Material Type | Polyolefin, crosslinked |
| Adhesive Type | EVA |
| Color | Black, Clear, Orange, Red, White, Yellow |
| Tubing Code | DWS125-55PXTEVR |
| Min Shrink Temp | 80 |
| Min Full Recovery Temp | 110 |
| Length Change | -7+3% |
| Halogen Free | No |
| RoHS | Yes |
| REACH | No |
| ELV | Yes |
| MIL | No |
| Low Op Temp | -55 |
| High Op Temp | 125 |
