Eurotech ET10 Dual Wall Heat Shrink Tubing
Thin Wall, Flame Retardant | -40 to 125C | EVA Adhesive | Low Viscosity, Thin

Description
Specifications

Eurotech ET10 Dual Wall Heat Shrink Tubing

Thin Wall, Flame Retardant | -40 to 125C | EVA Adhesive | Low Viscosity, Thin

Introducing Eurotech’s Dual Wall Heat Shrink Tubing:

Eurotech proudly presents its Dual Wall Heat Shrink Tubing line, engineered to deliver performance and durability in a wide range of applications. Our dual wall tubing combines the strength and insulation of outer jackets with the sealing properties of inner adhesive lining, providing reliable protection against moisture, chemicals, and damage.

*Key Features:

Enhanced Protection: Eurotech’s dual wall heat shrink tubing offers protection against environmental elements, ensuring reliability of electrical connections and components.
Sealing Properties: The inner adhesive lining creates a waterproof seal, preventing water ingress and providing additional insulation.
OEM Approvals: Our dual wall tubing has garnered OEM approvals, demonstrating its adherence to stringent quality and performance standards.
Versatile Applications: Ideal for automotive, marine, aerospace, and industrial applications, Eurotech’s dual wall tubing offers reliability across various industries.
Custom Solutions: We offer customization options to meet specific requirements, including sizes, colors, and shrink ratios.

Experience the durability and reliability of Eurotech’s Dual Wall Heat Shrink Tubing for your next project. Learn more about Eurotech’s heat shrink tubing here: https://www.eurotechdirect.com/heat-shrink-tubing/

*The Features listed above refer to the Eurotech Dual Wall product portfolio as a whole. Not every bullet is applicable to each individual product.

Additional information

Model	ET10
Wall Type	Dual Wall
Shrink Ratio	2:1, 3:1, 4:1, 5:1
ID Supplied / ID Recovered (mm)	12.0 / 3.0, 16.0 / 4.0, 18.0 / 6.0, 24.0 / 6.0, 32.0 / 8.0, 4.0 / 1.0, 5.5 / 1.1, 52.0 / 13.0, 6.4 / 2.1, 7.6 / 1.5, 8.0 / 2.0, 9.0 / 2.3
Mode	Shrinkable
Material Type	Polyolefin, crosslinked
Adhesive Type	EVA
Adhesive Feature	Low Viscosity,Thin
Color	Black, Blue, Brown, Clear, Green, Grey, Orange, Red, White, Yellow
Min Shrink Temp	90
Min Full Recovery Temp	125
Length Change	-7+3%
UL Rating	E515400
Halogen Free	No
RoHS	Yes
REACH	Yes
ELV	Yes
MIL	No
Low Op Temp	-40
High Op Temp	125
