ET008-50 BluSeal Advanced Sealing Solution by Eurotech (50 gram)
$68.00
8 in stock
Description
BluSeal Splice & Terminal Sealing Solution
BluSeal by Eurotech provides superior protection against water ingression and contaminants in splices and terminals. Drip and dip applied, BluSeal penetrates between wire strands and insulating jacket, curing to a durable / flexible barrier. BluSeal’s unique low-viscosity automotive-grade formulation has robust moisture and chemical resistance over a wide range of temperatures. BluSeal provides a permanent and effective seal, preventing corrosion failures over the life of the vehicle even on high wire count junctions.
BluSeal is a low viscosity liquid sealer that cures quickly, forming a durable, semi-flexible barrier. This unique automotive-grade formulation has excellent bend characteristics across a wide temperature range. It also offers robust moisture and chemical resistance. Used with a secondary insulator, BluSeal provides a permanent, effective seal for splices or terminals over the wire harness’s life.
Unlike other methods, BluSeal penetrates between each wire strand and under the insulating jacket. It then cures into a non-penetrable bond. BluSeal also permanently blocks water and contaminants, preventing corrosion failures.
Since BluSeal works at the wire-strand level, it can seal most splices. This is effective even with high wire counts and substandard construction, where other methods might fail. We also recommend design and process validation before serial production in your application.
Additional information
| Weight | 0.122 lbs |
|---|
Key Advantages to BluSeal:
- Very low-viscosity liquid sealer that cures quickly to form a durable and semi-flexible barrier
- Comprised of a unique automotive-grade formulation
- Excellent bend characteristics over a wide range of temperatures
- Extremely resistant to moisture and chemical exposure
- Provides a permanent and effective sealed splice over the life of the wire harness
- Seals by penetrating between each wire strand and deep under the wire insulating jacket
- Works at the wire-strand level and can provide sealing on most splice
- Becomes a semi-flexible acrylic polymer (plastic)
BluSeal Dip Machine for Splices (BDM)
The BluSeal Dip Machine (BDM) by Eurotech delivers highly controlled and reliable processing to meet the wire harness splice sealing requirements of world class automotive suppliers. Created with simple operation and user safety in mind, the BluSeal Dip Machine provides constant operational feedback, automated material control, and monitors performance to ensure every splice is sealed. Download Brochure
BluSeal Precision Drip Machine (BPDM)
The BluSeal Precision Drip Machine (BPDM) by Eurotech delivers simple and precise processing to meet wire harness terminal sealing requirements of world-class automotive suppliers. The BPDM combines a precise material dispenser and a 3-axis applicator with user friendly programming for the high-volume application of BluSeal in your manufacturing environment. Download Brochure
